OVERVIEW
Clashtrix is a powerful Navisworks plugin designed to streamline clash detection and resolution in BIM workflows. It enhances clash detection by automating tasks like tests and sets creation, matrix generation, clash grouping, exporting, and reporting, saving valuable time for BIM managers and coordination teams.
Why CLASHTRIX?
Clashtrix is a powerful Navisworks plugin developed from years of experience managing BIM projects of various scales. It goes beyond being just a tool—it standardizes and streamlines your clash detection and resolution workflow, ensuring consistent results and efficient collaboration. By automating manual processes, ClashTrix helps save valuable time and reduces the risk of human error. It provides a systematic approach that customizes reports to meet the unique needs of each project, improving accuracy and alignment with project-specific goals. With its suite of features, Clashtrix enables teams to work more efficiently, ensuring that clash management is both cost-effective and aligned with industry best practices. This comprehensive solution is designed to support the smooth execution of projects, from the smallest tasks to the most complex challenges, helping to deliver reliable, timely results.
+95
% time saving
100%
customized reports
+14
days free trial
+12
+ unique functions
Features
Tests Sets Builder
This tool automates the creation of selection sets and clash tests using data from a CSV file (You can use the csv generated from Export Categories tool). It streamlines clash detection workflows and enhances productivity for BIM professionals.
Key Features:
► Generate sets and tests based on elements categories.
► Set the clash test type, tolerance, composite object etc..
► Defined categories to be ingnored from the sets and tests creation.
► Combine several categories into a single set.
► Save the settings as default template to be used in future projects.
Clash Matrix
Export the clash results as a well-formatted Excel matrix. The exported matrix is organized by automatically detected discipline codes, featuring structured grouping, color coding, styled formatting, vertical text for column headers, and greyed-out empty cells. The displayed numbers represent the total of active and new clashes, while approved and reviewed clashes are excluded.
The results can also be exported in CSV table format. The exported summary will include the total number of clashes, along with counts for active, new, reviewed, approved, resolved, and total active clashes (new + active).
Group Clashes
Grouping clashes helps the team resolve them more efficiently. With multiple grouping options, the team can prioritize clash resolution based on location, element type, or high-density clash areas. This tool enables quick grouping across multiple clash tests simultaneously.
Contact UsPurge
Use this tool to delete clash tests based on specific criteria, allowing the team to focus on relevant clashes while reducing clutter in the clash test list. It also includes an option to remove all tests with zero results, ensuring a clean NWD file with a streamlined clash test list.
Contact UsExport Approved
Export all clashes marked as approved or reviewed for import into another file, ensuring updated clash statuses across disciplines.
Key Features:
► Exports only approved/reviewed clashes into a single XML file.
► Includes "Approved By" and "Approval Date" for approved clashes.
► Includes "Assigned To" for reviewed clashes.
► Works regardless of grouping changes in NWF/NWD.
Export Options:
► Filter by keyword in clash tests.
► Export all approved clashes.
► Export only those approved after a specific date.
► Option to include reviewed clashes.
Batch Actions
Easily apply clash test setting updates across multiple tests based on selected criteria. This tool is useful for making adjustments if settings were missed during initial clash test preparation.
How It Works:
► Use comma-separated search keywords to apply updates to matching tests.
► Leave the search field empty to update all clash tests.
Update Options:
► Modify tolerance values.
► Change clash test type (Hard | Hard Conservative | Clearance | Duplicates).
► Enable/disable Composite Object Clashing.
Purchase
Use below link to purchase a single 1-year license. For bulk purchase (10 licenses or more), please request a quote using the contact us form. Already made a purchase? Lookup your serial number using your Paypal transaction ID here.
Already purhased? Lookup your serial numbers here.
